FCXO-07F24.00MVdd0.9V20ppm-40C+85C-B

Oscillators Overview

The FCXO-07F24.00MVdd0.9V20ppm-40C+85C-B is a standard CMOS oscillator manufactured by River Eletec Corporation. It operates at a frequency of 24 MHz with a supply voltage of 0.9 V and a frequency stability of ±20 ppm across the -40°C to +85°C temperature range. The device features a standby (power down) function and is housed in a compact 4-SMD, No Lead package.

Oscillators Feature Summary

• Ultra-low supply voltage operation at 0.9 V
• Integrated standby mode for power management
• Standard CMOS output interface

Oscillators Applications

• Portable electronic devices requiring low power consumption
• Embedded systems with strict size constraints
• Battery-operated timing circuits

Oscillators Procurement Notes

Verify the specific ordering suffix matches the required voltage, stability, and temperature range. Confirm the package type and pin configuration against the target PCB footprint. Ensure the manufacturer source is authorized to guarantee component authenticity and traceability.

Oscillators Selection Notes

Select this component when ultra-low voltage operation and compact form factor are critical. Compare stability requirements against the ±20 ppm specification. Consider the operating temperature range limits for the intended environment.

Oscillators Part Context

This part belongs to the FCXO series from River Eletec Corporation, focusing on miniature crystal oscillators. The series emphasizes miniaturization and low power consumption for modern portable electronics.

Oscillators Replacement Considerations

Check for direct substitutes within the same series offering different voltage or stability options. Verify pin compatibility and electrical specifications before substituting.
