FH3000012Z

Crystals Overview

The FH3000012Z is a ceramic surface-mount crystal manufactured by Diodes Incorporated. It operates at a fundamental frequency of 30.0000 MHz with a specified load capacitance of 10 pF. The component features a frequency tolerance and stability of ±10 ppm, ensuring precise timing performance across its operational range. Designed for reliability, it supports an extended industrial temperature range from -30°C to +85°C. The device utilizes a SEAM2520 package format, suitable for automated surface-mount assembly processes in compact electronic designs.

Crystals Feature Summary

• Provides stable oscillation at 30 MHz with high frequency accuracy
• Operates reliably within an extended industrial temperature environment
• Utilizes a compact ceramic surface-mount package design

Crystals Applications

• General-purpose clock signal generation in embedded systems
• Timing reference sources for microcontroller units
• Synchronization circuits in consumer electronics devices

Crystals Procurement Notes

Verify the specific package marking and lot traceability against the official datasheet specifications prior to integration. Confirm that the supplier provides valid RoHS compliance documentation and material declarations as required by regulatory standards. Ensure that storage conditions adhere to manufacturer guidelines to maintain component integrity before soldering. Cross-reference the ordering part number suffixes to guarantee exact electrical parameter matching for the target application requirements.

Crystals Selection Notes

Select this component when a 30 MHz reference with tight ±10 ppm stability is required for industrial environments. The SEAM2520 footprint offers a balance between size constraints and thermal performance. Consider the 10 pF load capacitance requirement to ensure proper circuit tuning without additional external compensation components. Evaluate the extended temperature range suitability for applications exposed to varying environmental conditions during operation.

Crystals Part Context

This crystal belongs to the standard ceramic resonator family offered by Diodes Incorporated under the SaRonix-eCera brand line. These components are engineered for cost-effective mass production while maintaining strict frequency control. The product series targets applications requiring reliable timing solutions where space limitations necessitate surface-mount technology implementations.

Crystals Replacement Considerations

Direct substitutes must match the 30 MHz frequency, 10 pF load capacitance, ±10 ppm tolerance, and SEAM2520 package dimensions. Verify equivalent temperature ratings and electrical characteristics to ensure functional compatibility.
