FIN1900.100.M

Power Line Filter Modules Overview

The Enerdoor FIN1900.100.M is a three-phase (Delta) EMC/EMI line filter designed for industrial power applications. It features a two-stage configuration with terminal block connections, supporting a current rating of 100 A at 50/60 Hz. The unit provides high attenuation for differential and common mode noise while maintaining low leakage current. Rated for up to 600 VAC, it complies with UL508A SCCR requirements and supports CE certification testing.

Power Line Filter Modules Feature Summary

• Two-stage filtering architecture for enhanced noise suppression
• Compliance with UL508A short-circuit current rating standards
• Supports field CE conformity testing under IEC and EN regulations

Power Line Filter Modules Applications

• Industrial automation machinery
• Medical equipment power systems
• Machine tool electrical panels

Power Line Filter Modules Procurement Notes

Verify the specific voltage rating variant against your system requirements, as the series includes models rated for 500 VAC and 600 VAC. Confirm that the terminal block connection type matches your panel wiring infrastructure. Ensure the selected unit meets the required SCCR等级 for your control panel design to maintain compliance with safety standards.

Power Line Filter Modules Selection Notes

Select this model for three-phase Delta configurations requiring 100 A capacity. Consider the two-stage design for superior interference reduction compared to single-stage alternatives. Verify compatibility with existing terminal block mounting styles and ensure the physical dimensions fit within the designated enclosure space for optimal thermal management.

Power Line Filter Modules Part Context

This component belongs to the Enerdoor FIN1900 series, which specializes in electromagnetic compatibility solutions for industrial environments. The series is known for providing certified filtering options that facilitate regulatory compliance for machinery manufacturers operating in global markets requiring strict EMC adherence.

Power Line Filter Modules Replacement Considerations

Direct substitutes include other models within the Enerdoor FIN1900 series with matching current ratings, such as the FIN1900.080.M or FIN1900.115.M, provided the amperage requirements align with the application load.
