FIN26.006.M

Power Line Filter Modules Overview

The Enerdoor FIN26.006.M is a single-phase EMC/EMI line filter module designed for industrial and commercial electrical systems. It operates at 250VAC with a rated current of 6A at 50/60Hz. The unit features a single-stage configuration and utilizes terminal block connections for installation. Certified by CE, CSA, and cURus agencies, it provides electromagnetic interference suppression to protect equipment from environmental noise and prevent conducted emissions.

Power Line Filter Modules Feature Summary

• Single-stage EMI/RFI filtering architecture
• Terminal block connection interface
• Compliance with international safety standards

Power Line Filter Modules Applications

• Industrial automation control panels
• Commercial machinery power supplies
• Electrical equipment requiring EMC compliance

Power Line Filter Modules Procurement Notes

Verify the specific part number suffix against official Enerdoor documentation to ensure correct voltage and current ratings. Confirm that the terminal block type matches your wiring requirements. Check for valid certification marks such as CE or UL on the physical unit to guarantee authenticity and regulatory compliance before integration into safety-critical systems.

Power Line Filter Modules Selection Notes

Select this component when a single-phase solution is required for circuits up to 6A at 250VAC. Ensure the application environment supports the operating frequency range of 50/60Hz. Verify that the physical dimensions and terminal block spacing fit within the available enclosure space. Consider the need for certified components if the final assembly requires UL or CSA listing.

Power Line Filter Modules Part Context

This model belongs to the Enerdoor FIN26 series of power line filter modules. The series offers various current ratings and configurations tailored for different electromagnetic compatibility needs. These filters are engineered to address both conducted emissions and susceptibility issues in low-voltage AC power distribution networks commonly found in modern electronic infrastructure.

Power Line Filter Modules Replacement Considerations

Consult Enerdoor technical data for direct cross-references. Ensure any substitute maintains identical voltage, current, and frequency specifications. Verify that alternative models offer comparable attenuation characteristics and physical mounting interfaces to avoid redesigning the host equipment chassis or wiring harness.
