FKP2C011001D00HF00

FKP2C011001D00HF00 is listed in the Film Capacitors range at ChipApex. The manufacturer field lists WIMA. Its product description is FKP 2 1000 PF 63 VDC 4.5X6X7.2 P. Review the specifications below when checking this part for your BOM.

Film Capacitors specifications for FKP2C011001D00HF00

• Description：FKP 2 1000 PF 63 VDC 4.5X6X7.2 P
• Series：FKP 2
• Mfr：WIMA
• Package：Tape & Reel (TR)
• Capacitance：1000 pF
• Tolerance：±2.5%
• Voltage Rating - AC：40V
• Voltage Rating - DC：63V
• Dielectric Material：Polypropylene (PP)
• Operating Temperature：-55°C ~ 100°C
• Mounting Type：Through Hole
• Package / Case：Radial
• Size / Dimension：0.283" L x 0.177" W (7.20mm x 4.50mm)
• Height - Seated (Max)：0.236" (6.00mm)
• Termination：PC Pins
• Lead Spacing：0.197" (5.00mm)
• Applications：High Frequency, Switching; High Pulse, DV/DT
• Ratings：-
• Features：-
