FL2D-Z5-223

Common Mode Chokes Overview

The FL2D-Z5-223 is a common mode filter manufactured by Mornsun. It features a typical inductance of 22000 μH per winding (22 mH) and supports a maximum current of 0.5 A. The component operates within a temperature range of -40°C to +105°C. It provides effective anti-interference capabilities and complies with UL508 isolation requirements.

Common Mode Chokes Feature Summary

• Good temperature characteristics
• Compact dimensions
• High reliability

Common Mode Chokes Applications

• Signal line filtering
• Common mode noise suppression

Common Mode Chokes Procurement Notes

Verify the specific part number suffix against official Mornsun documentation to ensure correct inductance and current ratings. Confirm RoHS compliance status through the manufacturer's declaration. Check for any specific packaging or handling requirements defined in the datasheet before procurement.

Common Mode Chokes Selection Notes

Select this component when high inductance values are required for signal lines. Ensure the operating current does not exceed 0.5 A. Verify that the -40°C to +105°C temperature range meets the application environment. Consider the compact size for space-constrained designs.

Common Mode Chokes Part Context

This component belongs to the FL2D series of common mode filters from Mornsun. The series includes variants with different inductance values, such as FL2D-Z5-103 and FL2D-Z5-153. These components are designed for EMI suppression in electronic circuits.

Common Mode Chokes Replacement Considerations

FL2D-Z5-103 and FL2D-Z5-153 are related parts in the same series but have different inductance values. Direct substitution requires verifying that the alternative inductance meets the circuit requirements.
