Product Detailed Parameters
- Description：455KHZ SMD FILTER 3PADS H
- Series：FL
- Mfr：NextGen Components
- Package：Tape & Reel (TR)
- Frequency：455kHz Center
- Impedance：1.5kOhm
- Bandwidth：-
- Insertion Loss：5dB
- Filter Type：AM
- Mounting Type：Surface Mount
- Package / Case：3-SMD, J-Lead
- Size / Dimension：0.260" L x 0.236" W (6.50mm x 6.00mm)
- Height (Max)：0.165" (4.20mm)
Download product information
Overview
The FL455K0000S007 is a ceramic filter manufactured by NextGen Components, designed for AM signal processing applications. It operates at a center frequency of 455kHz and features an AC resistance value of 1.5kOhm. The component utilizes a 3-SMD package with J-Lead configuration. Key electrical specifications include a signal insertion attenuation of 5dB and a filtering design optimized for AM signals.
Feature Summary
- Optimized for AM signal filtering applications
- Utilizes 3-SMD J-Lead surface mount packaging
- Provides defined AC resistance characteristics
Applications
- AM radio receiver intermediate frequency stages
- Signal processing circuits requiring 455kHz filtering
- Consumer electronics with AM demodulation requirements
Procurement Notes
Verify the manufacturer designation as NextGen Components, which distributes genuine Leading-Tech products. Confirm the specific part number suffix matches the required 3-SMD J-Lead configuration. Ensure compatibility with AM signal processing designs requiring 455kHz center frequency and 1.5kOhm impedance. Check for RoHS compliance status if required by your assembly standards.
Selection Notes
Select this component when designing AM receivers requiring a 455kHz ceramic filter. The 3-SMD J-Lead form factor suits automated surface mount assembly processes. Consider the 1.5kOhm impedance match for interfacing with preceding amplifier stages. Verify that the 5dB insertion loss meets system sensitivity requirements.
Part Context
This component belongs to the ceramic filter category within NextGen Components' portfolio. It serves as a passive frequency-selective element in analog communication circuits. The product line includes various resonators and filters for different frequency bands and modulation types.
Replacement Considerations
Publicly confirmed substitute part numbers are not available in the provided documentation. Consult the manufacturer or authorized distributors for equivalent components with matching 455kHz center frequency and SMD J-Lead specifications.
