FLLDU300A026I0

Power Line Filter Modules Overview

The KEMET FLLDU300A026I0 is a single-phase power line filter designed for high-current industrial applications. It supports a rated voltage of 440VAC and operates at frequencies of 50/60Hz with a continuous current rating of 300A. The unit features a chassis mount configuration utilizing an M32 metric nut for secure installation. Electrical specifications include a maximum DC voltage of 750V and a capacitance value of 2 x 1 uF. The device functions within an operating temperature range of -40°C to 85°C, ensuring reliability in demanding environments.

Power Line Filter Modules Feature Summary

• High current handling capability of 300A for robust industrial power filtering
• Chassis mount design with M32 metric nut for secure mechanical integration
• Compliance with UL and IEC/EN safety standards for global deployment

Power Line Filter Modules Applications

• Industrial motor drive systems requiring EMI/RFI suppression
• High-power renewable energy inverters
• Heavy-duty manufacturing equipment power supplies

Power Line Filter Modules Procurement Notes

Verify the specific ordering suffix against the official KEMET datasheet to ensure correct terminal configuration and mounting hardware compatibility. Confirm that the M32 metric nut specification matches your chassis requirements. Check for updated compliance certifications such as UL and IEC/EN before finalizing procurement to meet regional regulatory standards.

Power Line Filter Modules Selection Notes

Select this component when a single-phase filter capable of handling 300A continuous current is required. Ensure the system voltage does not exceed 440VAC or 750VDC. Verify that the chassis mounting space accommodates the physical dimensions and that the M32 thread pitch aligns with available mounting points. Consider the operating temperature range of -40°C to 85°C for environmental suitability.

Power Line Filter Modules Part Context

This part belongs to the KEMET FLLDU series of power line filters, which are engineered for high-current EMC applications. The series typically offers robust attenuation performance for conducted emissions in industrial settings. The FLLDU300A026I0 specifically addresses needs for large-scale power conversion and distribution systems where significant current loads and strict electromagnetic interference limits coexist.

Power Line Filter Modules Replacement Considerations

Consult the official KEMET replacement guide for direct equivalents. Verify that any substitute maintains the 300A current rating, 440VAC voltage rating, and M32 mounting interface. Ensure electrical parameters such as capacitance and leakage current remain within acceptable tolerances for the specific application circuit.
