FLLE2032ASDI

Power Line Filter Modules Overview

The KEMET FLLE2032ASDI is a single-phase power line filter designed for chassis mounting. It features a rated voltage of 300 VAC and a current rating of 32 A. The unit operates at frequencies of 50 Hz and 60 Hz, with a leakage current of 790 uA. Key electrical parameters include a capacitance of 4700 pF and an inductance of 800 uH. Physical dimensions are 130.5 mm in length, 56.5 mm in width, and 48.5 mm in height. The device utilizes screw termination and functions within a temperature range of -25°C to +100°C.

Power Line Filter Modules Feature Summary

• Provides EMI/RFI noise suppression for single-phase AC power lines
• Constructed in a compact plastic housing suitable for chassis installation
• Complies with UL, CSA, and EN safety standards

Power Line Filter Modules Applications

• Industrial machinery power conditioning
• Medical equipment power supply filtering
• Automotive testing and charging infrastructure

Power Line Filter Modules Procurement Notes

Verify the specific suffix 'SDI' against official KEMET documentation to confirm terminal type and compliance certifications. Confirm availability status as distribution channels may list discontinued or limited stock items. Ensure mechanical fitment matches the specified chassis mount dimensions before procurement.

Power Line Filter Modules Selection Notes

Select this component when single-phase filtering is required for loads up to 32 A at 300 VAC. The 4700 pF capacitance value influences leakage current limits; verify system safety requirements against the 790 uA specification. Consider the 800 uH inductance for expected attenuation characteristics in the target frequency band.

Power Line Filter Modules Part Context

This part belongs to the KEMET FLLE2 series of single-phase EMI/RFI filters. These filters are engineered to meet EMC requirements for various electronic equipment. The series offers multiple current ratings and mounting options, with the FLLE2032 variant specifically addressing higher current applications in a robust plastic enclosure.

Power Line Filter Modules Replacement Considerations

Publicly confirmed substitute part numbers for the FLLE2032ASDI were not identified in the provided source material. Cross-referencing with other FLLE2 series models requires verification of matching electrical and mechanical specifications.
