FLZ6V2B

Single Zener Diodes Overview

The onsemi FLZ6V2B is a single-channel Zener diode with a nominal voltage of 6.2 V and a maximum power dissipation of 500 mW. It utilizes the DO-35 axial through-hole package, featuring two pins for mounting. The device specifies a Zener voltage tolerance of 5% and a test current of 5 mA. Electrical characteristics include a maximum Zener impedance of 10 Ω and a maximum reverse leakage current of 3 µA. Operating temperatures range from -65 °C to +200 °C, with a typical voltage temperature coefficient between 0.4 and 3.7 mV/°C.

Single Zener Diodes Feature Summary

• Provides stable voltage regulation at a nominal 6.2 V level
• Supports high-temperature operation up to +200 °C
• Utilizes an axial DO-35 package for through-hole integration

Single Zener Diodes Applications

• Voltage reference circuits
• Overvoltage protection
• General-purpose rectification

Single Zener Diodes Procurement Notes

Verify the exact suffix against official documentation, as variations may exist within the FLZ6 series. Confirm that the specific part number matches the required DO-35 package and 500 mW rating. Ensure compliance with RoHS standards if applicable to the project requirements. Cross-reference the manufacturer's latest datasheet to confirm availability and any potential obsolescence notices before finalizing procurement plans.

Single Zener Diodes Selection Notes

Select this component when a reliable 6.2 V reference is needed in a through-hole design. The wide operating temperature range makes it suitable for harsh environments. Verify that the 500 mW power rating meets the circuit's thermal dissipation needs. Consider the 5% tolerance for precision applications requiring tighter voltage control.

Single Zener Diodes Part Context

This component belongs to the FLZ6 series of Zener diodes manufactured by onsemi. The series offers various voltage options within a compact form factor. While the FLZ6V2B typically denotes a specific voltage variant, users should verify the exact part designation against official catalogs to ensure compatibility with existing designs and supply chain requirements.

Single Zener Diodes Replacement Considerations

Consult official substitution guides for compatible equivalents. Generic replacements must match the 6.2 V nominal voltage, 500 mW power rating, and DO-35 package dimensions. Verify electrical parameters such as impedance and leakage current to ensure functional parity.
