FM82P2004

Overview

The FM82P2004 is an analog phase shifter manufactured by Fairview Microwave, designed for signal conditioning applications. It operates within a frequency range of 2 GHz to 4 GHz and provides a continuous phase shift adjustment from 0 to 360 degrees. The component features SMA connectors for interface connectivity and exhibits an insertion loss between 4 dB and 5.5 dB. This module is categorized under general-purpose RF ICs and is suitable for systems requiring precise phase control within the specified microwave frequency band.

Feature Summary

• Provides continuous analog phase shift adjustment across a full 360-degree range
• Operates effectively within the 2 GHz to 4 GHz frequency spectrum
• Utilizes SMA connector interfaces for standard RF integration

Applications

• General-purpose RF signal conditioning systems
• Microwave communication equipment requiring phase alignment
• Test and measurement instrumentation modules

Procurement Notes

Verify the specific datasheet version and connector gender details prior to ordering, as product listings may vary in descriptive specificity. Confirm that the SMA interface type matches the system requirements. Ensure the operating frequency range aligns with the design specifications. Check for any recent updates to the component's electrical characteristics or mechanical dimensions in the official manufacturer documentation before finalizing procurement decisions.

Selection Notes

Select this component when a wideband analog phase shift capability is required between 2 GHz and 4 GHz. Consider the insertion loss specification of 4 to 5.5 dB for system power budget calculations. The SMA interface ensures compatibility with standard RF test fixtures and cable assemblies. Evaluate the physical module form factor against available board space constraints in the target application design.

Part Context

The FM82P2004 belongs to Fairview Microwave's portfolio of signal conditioning components, specifically within their analog phase shifter line. It serves as a modular solution for adjusting signal phase in microwave circuits. The device is classified under general-purpose RF integrated circuits and modules, distinguishing it from fixed-phase or digital step-shifter alternatives in the manufacturer's catalog.

Replacement Considerations

No public substitute part numbers are confirmed in the provided documentation. Direct replacement requires matching the 2-4 GHz frequency range, 360-degree phase shift capability, and SMA interface specifications. Verify electrical performance equivalence with alternative models from other manufacturers if sourcing changes occur.
