FM82P5021

Overview

The FM82P5021 is a 6-bit TTL programmable phase shifter manufactured by Fairview Microwave. It operates within a frequency range of 18 GHz to 26 GHz, providing a total phase shift range of 360 degrees. The device utilizes TTL logic for control and is designed for high-frequency signal conditioning applications requiring precise digital phase adjustment.

Feature Summary

• Provides 360-degree total phase shift capability across the operational band
• Utilizes 6-bit resolution for precise digital phase control
• Accepts TTL logic signals for programming and operation

Applications

• Phased array antenna systems
• Microwave test and measurement equipment
• High-frequency communication links

Procurement Notes

Verify current availability status as the component may be subject to backorder conditions. Confirm that the required TTL voltage levels match the system interface specifications before integration. Ensure proper handling procedures are followed due to the sensitive nature of RF integrated circuits.

Selection Notes

Select this component when a wideband 360-degree phase shift is required between 18 GHz and 26 GHz. The 6-bit resolution offers a balance between control precision and complexity. Verify compatibility with existing TTL control circuitry and ensure thermal management meets the requirements for continuous operation at these frequencies.

Part Context

This part belongs to Fairview Microwave's RF misc ICs and modules category. It serves as a general-purpose phase shifter for microwave frequencies. The device complements other signal conditioning components by providing digital control over signal phase in high-frequency transmission paths.

Replacement Considerations

No direct public substitute part numbers are confirmed. Evaluate alternative phase shifters based on frequency range (18-26 GHz), bit resolution (6-bit), and control interface (TTL) compatibility.
