FM82P5022

Overview

The FM82P5022 is a 6-bit TTL programmable phase shifter manufactured by Fairview Microwave. It operates within a frequency range of 6 GHz to 18 GHz and provides a total phase range of 360 degrees. The device features a control step size of 5.625 degrees, allowing for precise phase adjustment. It utilizes SMA connectors for signal interfacing and accepts TTL logic levels for digital control inputs. This component is designed for high-frequency signal conditioning applications requiring accurate phase manipulation.

Feature Summary

• Provides 6-bit digital phase shifting capability with a full 360-degree range
• Operates at microwave frequencies from 6 GHz to 18 GHz
• Features fine resolution with a 5.625-degree control step size
• Utilizes standard SMA connectors for RF interface

Applications

• Phased array antenna systems
• Microwave test and measurement equipment
• Radio frequency signal processing circuits
• Beamforming network implementations

Procurement Notes

Verify the specific datasheet version and connector gender details directly with the manufacturer or authorized distributor before ordering. Ensure that the TTL voltage levels match your system logic requirements. Confirm that the SMA interface type aligns with your existing PCB or cable infrastructure to guarantee proper integration and signal integrity in high-frequency designs.

Selection Notes

Select this component when precise digital phase control is required in the 6-18 GHz band. The 5.625-degree step size offers high resolution for complex beamforming tasks. Consider the physical footprint and thermal management needs associated with SMA-connected modules. Verify compatibility with your control logic voltage levels to ensure reliable operation without additional level-shifting circuitry.

Part Context

This part belongs to Fairview Microwave's signal conditioning portfolio, specifically focusing on programmable phase shifters. It serves as a critical element in modern RF systems where dynamic phase adjustment is necessary. The product line emphasizes high-frequency performance and digital controllability, catering to specialized communication and radar technologies.
