FM86GM2005

Overview

The FM86GM2005 is a bi-phase modulator manufactured by Fairview Microwave, designed for operation within the 6 GHz to 12 GHz frequency range. It features TTL control inputs and supports a switching speed of 15 nanoseconds. The device provides 0 or 180-degree phase shift capabilities and utilizes SMA connectors for interfacing.

Feature Summary

• Provides precise 0 or 180-degree bi-phase modulation
• Operates effectively across the 6 GHz to 12 GHz spectrum
• Features TTL-compatible digital control interface
• Supports rapid 15 nanosecond switching speeds

Applications

• Digital phase modulation systems
• Quadrature amplitude modulation (QAM) encoders
• Phase shift keying (PSK) communication links
• Radar signal processing circuits

Procurement Notes

Verify the specific SMA connector gender and pin configuration against your schematic requirements before ordering. Confirm that the TTL voltage levels match your system logic standards. Ensure the operating temperature range aligns with your environmental conditions. Request detailed electrical performance curves from the manufacturer for critical design validation.

Selection Notes

Select this component when high-speed phase inversion is required in microwave applications. The 15 ns response time suits dynamic modulation tasks. Verify impedance matching at SMA interfaces. Consider thermal management if continuous high-power operation is anticipated within the specified frequency band.

Part Context

This part belongs to Fairview Microwave's active RF component portfolio. It complements their passive cable assemblies and attenuators by providing active signal manipulation. The device integrates semiconductor technology for precise phase control in wireless infrastructure.

FAQ

What is the maximum switching speed?

The FM86GM2005 supports a switching speed of 15 nanoseconds.

Does it require analog or digital control?

It requires TTL digital control signals for phase state selection.
