FMBT1656

Overview

The FMBT1656 is an RF adapter classified as a Tee, manufactured by Fairview Microwave. It operates within a frequency range of 1 GHz to 6 GHz with a maximum frequency specification of 6 GHz. The component features SMA connectors and maintains a characteristic impedance of 50 Ohms. It is packaged in bags for distribution.

Feature Summary

• Provides broadband bias tee functionality via SMA connector interfaces
• Supports signal transmission across the 1 GHz to 6 GHz frequency spectrum

Applications

• RF test and measurement setups requiring bias injection
• Signal distribution systems operating within specified frequency limits
• Electronic equipment integrating DC power with RF signals

Procurement Notes

Verify the specific electrical ratings and connector gender configurations against the official Fairview Microwave datasheet before integration. Confirm that the 1 GHz to 6 GHz operational range aligns with system requirements. Ensure compatibility with existing 50 Ohm infrastructure. Check current availability status through authorized distributors as supply conditions may vary.

Selection Notes

Select this component when a bias tee configuration is required for frequencies up to 6 GHz. Ensure the application utilizes SMA connectors compatible with the 50 Ohm impedance standard. Verify that the physical dimensions and mounting style meet the design constraints. Compare performance specifications against alternative adapters if higher frequency operation beyond 6 GHz is necessary.

Part Context

This part belongs to the Fairview Microwave RF Adapters category, specifically under the Tee subcategory. It is designed for applications requiring the combination of DC bias and RF signal paths using standard SMA interfaces. The product line focuses on providing reliable connectivity solutions for radio frequency environments.
