FMFX2021

Overview

The FMFX2021 is an active frequency multiplier module manufactured by Fairview Microwave. It functions as a frequency doubler, accepting an input signal within the 13.25 GHz to 20 GHz range and producing an output at 26.5 GHz to 40 GHz. The device utilizes SMA connectors for both input and output interfaces. It is designed for general-purpose RF applications requiring precise frequency conversion in microwave systems.

Feature Summary

• Active frequency doubling capability converting lower microwave inputs to higher mmWave outputs
• Integrated SMA connector interface for straightforward system integration
• General-purpose RF module design suitable for broad microwave testing environments

Applications

• Microwave test and measurement instrumentation
• Signal generation systems requiring frequency up-conversion
• Communication equipment development and validation

Procurement Notes

Verify component authenticity through authorized Fairview Microwave channels or certified distributors. Confirm that the received unit matches the specific FMFX2021 designation and includes original documentation. Inspect packaging integrity to ensure SMA connectors are undamaged. Validate performance specifications against the official datasheet prior to deployment in critical systems.

Selection Notes

Select this module when a fixed frequency doubling function is required for signals between 13.25 GHz and 20 GHz. Ensure system impedance matches the 50 Ohm standard implied by SMA interfaces. Consider thermal management requirements as active multipliers generate heat. Verify that the output frequency range of 26.5 GHz to 40 GHz aligns with downstream component capabilities.

Part Context

Fairview Microwave specializes in high-frequency RF, microwave, and millimeter-wave components. The FMFX2021 belongs to their portfolio of signal conditioning modules designed for precision applications. This product supports engineers needing reliable frequency multiplication without complex discrete circuit implementation, fitting into broader RF subsystem architectures.

Replacement Considerations

No public substitute part numbers are documented for the FMFX2021. Direct replacement requires identical frequency multiplication characteristics and SMA interface compatibility. Custom solutions may be necessary if exact specifications cannot be met by available inventory.
