Product Detailed Parameters
- Description：WR-19 WAVEGUIDE WITH UG-383/U-M
- Series：-
- Mfr：Fairview Microwave
- Package：Bag
- Function：Multiplier
- Frequency：10GHz ~ 15GHz
- RF Type：General Purpose
- Secondary Attributes：SMA Connectors
- Mounting Type：Chassis Mount
- Package / Case：Module
- Supplier Device Package：Module
- Grade：-
- Qualification：-
Download product information
Overview
The FMFX2022 is a frequency multiplier module manufactured by Fairview Microwave. It accepts an input signal within the 10 GHz to 15 GHz range and generates an output at 40 GHz to 60 GHz, functioning as a 4x multiplier. The device supports an input power level of 0 dBm to 10 dBm and utilizes SMA connectors for interfacing. Packaged in a bag with a factory pack quantity of one, this component is designed for high-frequency signal generation applications.
Feature Summary
- Performs four-fold frequency multiplication from input to output bands
- Operates across millimeter-wave frequencies up to 60 GHz
- Features SMA connector interfaces for standard integration
Applications
- Millimeter-wave test and measurement systems
- High-frequency signal generation modules
- Radar system components
Procurement Notes
Verify the specific datasheet version for the FMFX2022 to confirm exact electrical tolerances and pinout configurations before integration. Ensure that the host system provides the required 10 to 15 GHz input signal within the specified power limits. Confirm mechanical compatibility with existing SMA connections and verify thermal management requirements for continuous operation at 60 GHz outputs.
Selection Notes
Select the FMFX2022 when a compact solution is needed to generate 40 to 60 GHz signals from lower frequency sources. This module is suitable for designs requiring a fixed 4x multiplication ratio without external synthesizer complexity. Consider the SMA interface constraints and ensure the application can accommodate the physical dimensions and weight associated with this specific module form factor.
Part Context
Fairview Microwave specializes in RF, microwave, and mmWave components, offering extensive catalog options. The FMFX2022 belongs to their active electronic component portfolio, distinct from passive cable assemblies or attenuators. This product represents the manufacturer's capability in providing integrated active frequency conversion solutions for specialized communication and testing environments.
Replacement Considerations
No public confirmed substitute part numbers are available for the FMFX2022. Engineers must evaluate alternative multipliers based on matching frequency ranges, multiplication ratios, and connector types rather than direct cross-referencing.
