Product Detailed Parameters
- Description：VOLT CONTROL OSC 30MHZ-60MHZ
- Series：-
- Mfr：Fairview Microwave
- Package：Bag
- Frequency Range：-
- Frequency - Center：-
- Voltage - Supply：-
- Tuning Voltage (VDC)：-
- 2nd Harmonic, Typ (dBc)：-
- Icc Max：-
- Pushing (MHz/V)：-
- Power (dBm)：-
- Phase Noise Typ (dBc/Hz)：-
- Operating Temperature：-
- Package / Case：-
- Size / Dimension：-
- Height：-
Download product information
Overview
The FMVC11003 is a Voltage Controlled Oscillator (VCO) manufactured by Fairview Microwave. It features a center frequency of 45 MHz and operates with an input voltage range of 0 V to 15 V. The device provides an output power of 11 dBm and exhibits a typical second harmonic level of -14 dBc. Designed for reliability, it is housed in a grounded case configuration suitable for integration into RF systems requiring stable signal generation.
Feature Summary
- Voltage-controlled operation utilizing a 0 V to 15 V tuning range
- Grounded metal case construction for effective shielding
- Stable 45 MHz center frequency performance
- Integrated output power specification of 11 dBm
Applications
- RF signal generation circuits
- Frequency synthesis modules
- Test and measurement instrumentation
- Communication system local oscillators
Procurement Notes
Verify the specific datasheet revision and mechanical drawings before integration. Confirm that the 0-15 V control voltage aligns with your system's supply rails. Ensure thermal management meets the requirements for continuous 11 dBm output operation. Check compatibility with existing PCB layouts regarding the grounded case design.
Selection Notes
Select this component when a fixed 45 MHz center frequency with voltage tunability is required. Consider the 11 dBm output power for direct driving capabilities. Evaluate the -14 dBc second harmonic performance against spectral purity requirements. Compare physical dimensions and grounding schemes with alternative VCO packages.
Part Context
Fairview Microwave specializes in high-quality RF, microwave, and mmWave components. The FMVC11003 represents their portfolio of voltage-controlled oscillators designed for precision applications. This part supports engineers needing reliable frequency sources within established RF infrastructure standards.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Verify pinout and electrical specifications carefully if considering alternatives from other manufacturers.
