FMWAN022-15OMT

Antennas RF Overview

The FMWAN022-15OMT is a dual polarized horn antenna manufactured by Fairview Microwave, designed for WR-22 waveguide applications. It operates within a frequency range of 33 GHz to 50 GHz and provides a nominal gain of 15 dBi. The unit features a UG-383/U flange interface for secure mounting and connection. This component is categorized under outdoor antennas and serves as a specialized solution for high-frequency signal transmission and reception in millimeter-wave systems requiring precise polarization control.

Antennas RF Feature Summary

• Dual polarized radiation pattern for enhanced signal versatility
• Horn antenna geometry optimized for WR-22 waveguide compatibility
• UG-383/U flange interface ensures standardized mechanical integration

Antennas RF Applications

• Millimeter-wave communication link testing
• Radar system development and evaluation
• Satellite ground station signal acquisition

Antennas RF Procurement Notes

Verify the specific datasheet documentation for the FMWAN022-15OMT to confirm current manufacturing status and technical specifications. Ensure that the receiving equipment supports the WR-22 waveguide standard and UG-383/U flange configuration. Cross-reference the frequency range requirements with your system design to guarantee operational compatibility within the 33 GHz to 50 GHz band before finalizing procurement decisions.

Antennas RF Selection Notes

Select this model when a dual-polarized solution is required for WR-22 waveguide systems operating between 33 GHz and 50 GHz. The 15 dBi nominal gain makes it suitable for point-to-point links or test setups where moderate directivity is necessary. Consider the physical dimensions and weight constraints associated with the horn structure and UG-383/U flange mount during mechanical integration planning.

Antennas RF Part Context

Fairview Microwave produces this component as part of its broader portfolio of RF and microwave products. The FMWAN022-15OMT falls under the category of outdoor antennas and specifically utilizes horn antenna technology. It is engineered for high-frequency performance, aligning with the company's focus on providing specialized solutions for defense, aerospace, and test measurement industries requiring reliable millimeter-wave components.
