FMWAN1061

Antennas RF Overview

The FMWAN1061 is a general-purpose horn antenna manufactured by Fairview Microwave. It operates within the frequency range of 8 GHz to 18 GHz and provides a gain of 10 dBi. The component features an SMA female connector interface and utilizes a screw-mount installation style. Designed for waveguide mounting applications, this broadband antenna is suitable for high-frequency signal transmission and reception tasks requiring stable directional performance across its specified operational bandwidth.

Antennas RF Feature Summary

• Broadband operation covering 8 GHz to 18 GHz
• SMA female connector interface
• Screw-mount installation style

Antennas RF Applications

• Waveguide mounting systems
• High-frequency signal transmission
• Directional communication links

Antennas RF Procurement Notes

Verify availability through authorized distributors as stock status may be limited. Confirm technical specifications against the official datasheet before integration. Ensure compatibility with existing SMA interfaces and mounting hardware. Check for any regional shipping restrictions or supply chain limitations that may affect procurement timelines.

Antennas RF Selection Notes

Select this model when a broadband horn antenna is required for frequencies between 8 GHz and 18 GHz. Consider the 10 dBi gain and SMA connector type for system compatibility. Evaluate the screw-mount design against available space and structural requirements in the intended application environment.

Antennas RF Part Context

This component belongs to the RF antennas category from Fairview Microwave. It is part of a series of broadband horn antennas designed for specific frequency bands. The FMWAN1061 serves as a specialized solution for applications demanding reliable performance in the microwave spectrum.
