FMWAN1065

Antennas RF Overview

The FMWAN1065 is a WR-5 waveguide conical gain horn antenna manufactured by Fairview Microwave. It operates within the frequency range of 140 GHz to 220 GHz. The component provides a nominal gain of 10 dBi. It is designed for high-frequency microwave applications requiring precise directional radiation patterns.

Antennas RF Feature Summary

• Conical horn design optimized for WR-5 waveguide interfaces
• Operates in the extremely high frequency band from 140 GHz to 220 GHz
• Provides stable nominal gain performance across the specified bandwidth

Antennas RF Applications

• Millimeter-wave testing and measurement systems
• Satellite communication uplink and downlink links
• Radio astronomy instrumentation
• High-frequency radar research and development

Antennas RF Procurement Notes

Verify the specific WR-5 flange configuration and polarization options required for your system integration. Confirm that the operating environment supports the extreme frequencies of 140 GHz to 220 GHz. Ensure compatibility with existing waveguide components and mounting hardware. Review the full datasheet for detailed VSWR and beamwidth specifications before finalizing the order.

Antennas RF Selection Notes

Select this model when a WR-5 interface is mandatory for frequencies above 140 GHz. Consider the physical size constraints associated with waveguide horns at these wavelengths. Evaluate if the 10 dBi gain meets the link budget requirements. Compare against standard rectangular waveguide antennas if lower frequency flexibility is needed.

Antennas RF Part Context

Fairview Microwave specializes in RF, microwave, and wireless passive components. The FMWAN1065 belongs to their waveguide antenna series, targeting niche high-frequency markets. This product complements their broader portfolio of adapters and cable assemblies covering ranges up to 110 GHz, extending into the sub-terahertz spectrum.

Antennas RF Replacement Considerations

Check for other WR-5 conical horns from Fairview Microwave with different gain ratings or beamwidths. Verify if alternative manufacturers offer compatible WR-5 waveguide antennas. Ensure any substitute matches the exact 140-220 GHz frequency range and mechanical flange dimensions.
