Product Detailed Parameters
- Description：NOISE GEN 40000 MHZ - 60 GHZ 28
- Series：-
- Mfr：Fairview Microwave
- Package：Bag
- Function：Noise Source
- Frequency：40GHz ~ 60GHz
- RF Type：Radar
- Secondary Attributes：28V Supply
- Mounting Type：Chassis Mount
- Package / Case：Module
- Supplier Device Package：-
- Grade：-
- Qualification：-
Download product information
Overview
The FMWNS2002 is a WR-19 waveguide noise source module manufactured by Fairview Microwave, designed for high-frequency applications within the U band. It operates across a frequency range of 40 GHz to 60 GHz and requires a maximum supply voltage of 28 VDC. The component features an integrated output isolator to ensure signal stability. It provides a minimum Excess Noise Ratio (ENR) level of 15 dB, making it suitable for precise calibration tasks in radar and communication systems.
Feature Summary
- Utilizes WR-19 waveguide architecture for operation in the U band frequency range
- Includes an integrated output isolator to maintain signal integrity
- Delivers a minimum Excess Noise Ratio (ENR) of 15 dB
Applications
- Radar system testing and calibration
- High-frequency communication equipment verification
- Noise figure measurement instrumentation
Procurement Notes
Verify that the specific unit matches the WR-19 waveguide specification and confirms the 40 GHz to 60 GHz operational range. Ensure compatibility with the required 28 VDC power supply before integration. Confirm the ENR rating meets the minimum 15 dB requirement for your specific calibration needs. Check for any updated datasheets regarding connector types or mounting requirements.
Selection Notes
Select this model when a dedicated U band noise source is required for frequencies between 40 GHz and 60 GHz. The inclusion of an output isolator makes it preferable for setups requiring stable noise injection without reflection sensitivity. Consider the WR-19 interface compatibility with existing test fixtures. This module is distinct from coaxial noise sources due to its waveguide design.
Part Context
This component belongs to Fairview Microwave's RF miscellaneous ICs and modules category. It serves as a specialized test instrument rather than a general-purpose amplifier or cable assembly. The product is identified by Mouser Taiwan under the manufacturer Fairview Microwave, highlighting its role in professional RF testing environments.
Replacement Considerations
No public confirmed substitute part numbers are available in the provided documentation. Users should verify interface compatibility if considering alternative waveguide noise sources.
