FMWPR028-7 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Fairview Microwave. Its product description is WG ANTENNA WR-28 26.5-40 GHZ. Review the specifications below when checking this part for your BOM.
Antennas RF specifications for FMWPR028-7
- Description：WG ANTENNA WR-28 26.5-40 GHZ
- Series：-
- Mfr：Fairview Microwave
- Package：Bag
- RF Family/Standard：General ISM
- Frequency Group：SHF (f > 4GHz)
- Frequency (Center/Band)：33.25GHz
- Frequency Range：26.5GHz ~ 40GHz
- Antenna Type：Horn
- Number of Bands：1
- VSWR：1.5
- Return Loss：-
- Gain：6.5dBi
- Features：Cable - 305mm, Cable - 1.524m, Cable - 3.048m, Cable - 7.62m
- Termination：Screw-Mount
- Ingress Protection：-
- Grade：-
- Qualification：-
- Mounting Type：Waveguide Mount
- Height (Max)：2.800" (71.12mm)
- Applications：General Purpose
- Power - Max：-
Antennas RF datasheet and documents for FMWPR028-7
Antennas RF Overview
The FMWPR028-7 is a WR-28 waveguide probe antenna manufactured by Fairview Microwave, designed for operation within the 26.5 GHz to 40 GHz frequency range. This component provides standard gain performance suitable for millimeter-wave applications. It features a waveguide mount configuration and is constructed to meet RoHS compliance standards. The unit serves as a specialized RF antenna solution for high-frequency signal transmission and reception in defined waveguide systems.
Antennas RF Feature Summary
- Operates as a WR-28 waveguide probe antenna
- Supports frequency range from 26.5 GHz to 40 GHz
- Features waveguide mount installation type
Antennas RF Applications
- Millimeter-wave testing environments
- RF measurement setups requiring standard gain
- Waveguide system integration
Antennas RF Procurement Notes
Verify that the specific application requires a WR-28 waveguide interface compatible with the 26.5 GHz to 40 GHz band. Confirm mechanical mounting requirements align with the waveguide mount specification. Ensure environmental conditions are within operational limits for standard gain horn antennas. Check for any specific calibration or traceability documentation needs prior to deployment.
Antennas RF Selection Notes
Select this model when a fixed-frequency waveguide antenna is required for the E-band spectrum. Consider the physical dimensions and mounting constraints associated with WR-28 waveguide flanges. Evaluate if the standard gain characteristics meet the link budget requirements. Compare against other Fairview Microwave waveguide components for system consistency.
Antennas RF Part Context
This component belongs to the Fairview Microwave waveguide antenna series, specifically tailored for high-frequency operations. It complements other RF interconnects and signal conditioning products offered by the manufacturer. The product line focuses on reliable performance in millimeter-wave frequencies, supporting various industrial and scientific applications requiring precise RF signal handling.
