FN2020B-10-06

Overview

The Schaffner FN2020B-10-06 is a single-phase, single-stage power line filter designed for chassis mounting. It features a rated current of 10 A and a voltage rating of 250 VAC. The component utilizes fast-on terminals for electrical connection and incorporates IEC 320-C14 inlet connector style. This module provides standard EMI/RFI filtering suitable for medical applications.

Feature Summary

• Single-phase single-stage filtering configuration
• Chassis mount installation style
• Fast-on terminal connection type

Applications

• Medical equipment power input
• Industrial control systems
• Electronic device EMC protection

Procurement Notes

Verify the specific datasheet version for the FN2020B-10-06 to confirm current production status and detailed dimensional drawings. Ensure that the fast-on terminal specifications match the system wiring requirements. Cross-reference with official TE Connectivity / Schaffner documentation to validate compliance certifications and thermal ratings before integration.

Selection Notes

Select this model when a 10 A capacity and 250 VAC rating are required for single-phase applications. The chassis mount design suits enclosed industrial or medical enclosures. Verify that the fast-on termination method aligns with available harness connectors. Confirm that the physical dimensions fit the designated chassis opening space.

Part Context

This component belongs to the FN 2020 series of power line filters manufactured by TE Connectivity / Schaffner. The series offers various current ratings and mounting options. The FN2020B-10-06 specifically addresses the 10 A requirement within this lineup, providing standardized filtering performance for professional electronic applications.

Replacement Considerations

Consult official manufacturer substitution lists for verified alternatives. Generic cross-references may not match the precise electrical characteristics or mechanical footprint required for certified medical or industrial installations.
