FN2060B-12-06

Overview

The FN2060B-12-06 is a single-phase, two-stage power line filter manufactured by TE Connectivity / Schaffner. It features a chassis mount design with Faston terminals for electrical connection. The component is rated for an AC voltage of 250 VAC and a continuous current of 12 A. It operates within a frequency range of 0 Hz to 400 Hz and has a maximum operating temperature of +100°C. Physical dimensions are approximately 85 mm in length, 54 mm in width, and 30.3 mm in height, with a weight of 190 g. The unit complies with UL, CSA, and IEC/EN safety standards.

Feature Summary

• Two-stage filtering configuration for enhanced EMI suppression
• Medical-grade construction suitable for sensitive equipment
• Chassis mounting style for secure installation
• Faston terminal connections for simplified wiring

Applications

• Medical electronic devices requiring low leakage current
• Industrial control systems needing robust EMI protection
• Power supplies for sensitive instrumentation
• General purpose applications in medical environments

Procurement Notes

Verify the specific suffix 'B' indicates medical compliance requirements against your system's safety standards. Confirm that the Faston terminal type matches your connector specifications. Ensure the chassis mounting hole pattern aligns with your enclosure design. Check for updated certification marks such as UL or CSA on the latest datasheet versions before finalizing procurement.

Selection Notes

Select this model when a 12 A rating is required for single-phase applications. The two-stage design offers higher attenuation compared to single-stage alternatives. Consider the physical dimensions and chassis mount requirement during mechanical design. Verify that the 250 VAC rating meets the input voltage specifications of the target application.

Part Context

This component belongs to the FN2060 series of single-phase AC/DC chassis filters. The series includes various current ratings and configurations. The 'B' suffix typically denotes medical grade variants with specific leakage current characteristics. This series is designed for general-purpose and medical applications requiring reliable EMI filtering.

Replacement Considerations

FN2060-12-06 is a non-medical equivalent within the same series. FN2060A-6-06 offers a lower current rating of 6 A. Verify compatibility with existing mounting hardware and terminal types when substituting.
