FN2200-150-40

Overview

The Schaffner FN2200-150-40 is a single-stage DC EMC/EMI line filter designed for photovoltaic inverters. It supports a maximum voltage rating of 1200VDC and handles up to 150A current. The unit features chassis mounting with terminal block termination and includes four terminals. Certified as an unsymmetrical filter, it operates within standard industrial temperature ranges.

Feature Summary

• Designed specifically for photovoltaic inverter applications
• Compact form factor for dedicated DC filtering
• Unsymmetrical filter architecture

Applications

• Photovoltaic (PV) inverters
• DC power distribution systems
• Industrial DC equipment requiring EMI suppression

Procurement Notes

Verify the specific voltage and current ratings against system requirements before ordering. Confirm that the terminal block termination style matches the existing wiring infrastructure. Ensure the chassis mount dimensions fit the available enclosure space. Check for any recent packaging changes or RoHS compliance updates in the official documentation.

Selection Notes

Select this component when high-current DC filtering is required for PV inverters. The 150A rating and 1200VDC capability define its operational limits. Consider the terminal block connection method for ease of assembly compared to busbar options. Verify compatibility with the specific inverter topology due to its unsymmetrical design.

Part Context

This part belongs to the FN2200 series, which provides compact DC filters for renewable energy applications. It serves as a specialized solution for suppressing electromagnetic interference in high-power DC circuits, distinct from general-purpose AC line filters.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material.
