FN2200B-50-34

Overview

The Schaffner FN2200B-50-34 is a single-phase EMI/EMC power line filter designed for DC applications. It features a voltage rating of 1.2 kVDC and a current capacity of 50 A. The unit utilizes chassis mount installation with terminal block termination. Certified to UL, CSA, and IEC/EN standards, it operates within a temperature range of -40°C to +100°C. Dimensions are 170 mm in length and 80 mm in height.

Feature Summary

• Designed specifically for medical DC power line filtering applications
• Provides robust electromagnetic interference suppression for sensitive equipment
• Constructed for durable chassis mounting with secure terminal block connections

Applications

• Medical DC power supply systems
• Industrial DC power distribution networks
• High-voltage DC electronic equipment requiring EMI mitigation

Procurement Notes

Verify the specific suffix 'B' against official datasheets to confirm medical certification status and exact electrical ratings. Ensure terminal block compatibility matches existing wiring infrastructure. Confirm thermal management requirements align with the specified operating temperature range during system integration.

Selection Notes

Select this component when high-voltage DC isolation and strict EMI compliance are required. The 1.2 kVDC rating distinguishes it from standard AC filters. Verify that the 50 A continuous current rating exceeds peak load demands. Consider physical dimensions for chassis space allocation before finalizing the design.

Part Context

This model belongs to the FN2200 series, which focuses on high-performance DC filtering solutions. The series is engineered for demanding environments where reliable noise suppression and safety compliance are critical. It complements other Schaffner components in complete power conditioning assemblies.

Replacement Considerations

Consult official substitution guides for equivalent models. Verify that any alternative maintains identical voltage, current, and mounting specifications. Cross-reference certification requirements to ensure regulatory compliance remains intact.
