FN2211-1000-99-C30-R55

$800.06

Description：LINE FLTR 1000VDC 1KA CHASS MNT
Series：FN 2211
Mfr：Schaffner EMC Inc.
Package：Box

SKU:4a1a5b287e82 Category: Power Line Filter Modules Brand: Schaffner EMC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LINE FLTR 1000VDC 1KA CHASS MNT
Series：FN 2211
Mfr：Schaffner EMC Inc.
Package：Box
Filter Type：DC
Configuration：Single Stage
Voltage - Rated DC：1000V (1kV)
Voltage - Rated AC：-
Current：1 kA
Frequency - Operating：DC
Applications：Inverters, Power Drive Systems
Approval Agency：CE, cURus
Operating Temperature：-40°C ~ 100°C
Mounting Type：Chassis Mount
Termination Style：Terminal Post
Inductance：-

Download product information

FN2211-1000-99-C30-R55

Overview

The FN2211-1000-99-C30-R55 is a single-phase EMC/EMI power line filter module manufactured by Schaffner EMC Inc. Designed for chassis mounting, this component supports a rated DC voltage of 1000V and a continuous current of 1000A. It operates within a frequency range of DC to 400Hz and features a two-stage filtering configuration with quick-connect terminals. The unit complies with RoHS3 standards and holds CE and cURus certifications.

Feature Summary

Provides high-current EMI suppression for demanding industrial power applications
Engineered for direct chassis installation using quick-connect termination style
Capable of handling extreme current loads up to 1000A at 1000VDC

Applications

Inverter systems
Power drive systems

Procurement Notes

Verify the complete part number including suffixes against official manufacturer documentation before ordering. Confirm that the specific terminal configuration and mounting requirements match the target equipment design. Ensure compliance with relevant safety certifications such as CE and cURus is required for the intended market. Cross-reference technical specifications directly with the latest datasheet to avoid discrepancies.

Selection Notes

Select this model specifically for applications requiring high-current DC filtering up to 1000A. Ensure the system voltage does not exceed the 1000VDC rating. Verify that the chassis mounting style and quick-connect terminals are compatible with the assembly process. Consider the physical dimensions and thermal management requirements associated with high-current operation in the final design.

Part Context

This component belongs to the FN2211 series of power line filter modules from Schaffner EMC Inc. The series is characterized by robust construction for industrial environments. These filters are distinct from lower-current AC variants and are optimized for high-power DC bus applications where significant electromagnetic interference suppression is necessary.
