FN2412-32-33

Overview

The Schaffner FN2412-32-33 is a single-phase EMC/RFI power line filter rated for 32 A and 250 VAC. It operates within a frequency range of 0 Hz to 400 Hz and features terminal block connections with DIN rail mounting. The unit exhibits a leakage current of 2.6 mA and functions between -25°C and +100°C. It holds UL, CSA, and IEC/EN certifications.

Feature Summary

• Industrial-grade terminal blocks designed for enhanced electrical safety
• High saturation resistance chokes providing exceptional conducted attenuation performance
• DIN rail mounting style for secure installation

Applications

• Power supply units
• Motor drives
• Medical equipment
• Industrial automation systems

Procurement Notes

Verify the specific suffix against official TE Connectivity/Schaffner documentation to confirm exact pinout and certification status. Ensure the procurement channel provides valid UL and CSA compliance records. Confirm that the terminal block type matches the system's wiring requirements before finalizing the order.

Selection Notes

Select this component when high current handling up to 32 A is required in a single-phase configuration. The DIN rail form factor suits applications needing robust mechanical stability. Verify that the 250 VAC rating aligns with the local mains voltage standards and that the thermal operating range covers the intended environment.

Part Context

This model belongs to the FN2412 series from Schaffner, specialized for industrial environments. The series utilizes advanced choke technology to manage electromagnetic interference effectively. It serves as a critical interface for protecting sensitive electronics from line noise while maintaining high current capacity.

Replacement Considerations

Consult official cross-reference lists for verified substitutes. Ensure any replacement maintains identical current ratings, voltage limits, and mounting configurations to preserve system integrity and compliance.
