Product Detailed Parameters
- Description：LINE FLTR 400VDC 277VAC 15A CHAS
- Series：FN2500
- Mfr：Schaffner EMC Inc.
- Package：Bulk
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：400V
- Voltage - Rated AC：277V
- Current：15 A
- Frequency - Operating：DC ~ 60Hz
- Applications：General Purpose
- Approval Agency：CE, CQC, CSA, ENEC, UKCA, UR
- Operating Temperature：-40°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Terminal Post
- Inductance：4mH
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The Schaffner FN2500-15-05-C13 is a single-phase EMC/EMI power line filter designed for chassis or rack mounting. It features a 15 A current rating and operates at voltages up to 277 VAC. The unit utilizes screw termination for secure electrical connections. Key specifications include an 870 µA leakage current and a capacitance of 10 nF. It supports frequencies from 0 Hz to 60 Hz and complies with RoHS standards.
Feature Summary
- Provides effective attenuation of electromagnetic interference in single-phase AC power circuits
- Designed for robust chassis or rack mounting applications
- Utilizes screw termination for reliable electrical connectivity
Applications
- Industrial machinery power supply filtering
- Medical equipment EMI suppression
- General-purpose electronic device noise reduction
Procurement Notes
Verify the specific part number against official TE Connectivity/Schaffner documentation to ensure compatibility with your system's voltage and current requirements. Confirm that the screw termination style matches your wiring infrastructure. Check for updated compliance certifications such as UL, CSA, and CQC before finalizing procurement decisions.
Selection Notes
Select this component when a single-phase filter with a 15 A rating is required for chassis-mounted installations. Ensure the operating frequency range of 0–60 Hz aligns with your power source. Verify that the 277 VAC rating meets your circuit's maximum voltage needs and that the physical dimensions fit your enclosure constraints.
Part Context
This model belongs to the FN2500 series of single-phase filters from Schaffner. The series is known for providing cost-effective EMC solutions for general-purpose filtering requirements. These filters are engineered to meet stringent international safety and EMC standards for industrial and commercial applications.
Replacement Considerations
Consult official manufacturer substitution guides for verified equivalents. Cross-referencing with distributor databases may identify compatible parts, but only officially confirmed substitute part numbers should be considered for direct replacement without redesign.
