FN2500-20-07-C13

Overview

The Schaffner FN2500-20-07-C13 is a single-phase power line filter designed for chassis mounting. It features screw termination and operates within a frequency range of DC to 400 Hz. The component has a rated voltage of 277 VAC and a current rating of 20 A. Key electrical parameters include a capacitance of 10 nF, a leakage current of 870 uA, and compliance with RoHS standards.

Feature Summary

• Provides EMI/EMC filtering for single-phase AC/DC power lines
• Designed for secure chassis mounting applications
• Utilizes screw termination for reliable electrical connections

Applications

• Industrial equipment power conditioning
• Medical device power supply input filtering
• Test and measurement instrument protection

Procurement Notes

Verify the specific suffix C13 against the manufacturer datasheet to confirm terminal configuration and certification status. Ensure the application environment does not exceed the 277 VAC or 20 A ratings. Confirm that the chassis mounting style aligns with the system enclosure design requirements before finalizing procurement.

Selection Notes

Select this model when a single-phase filter with a 20 A capacity is required for frequencies up to 400 Hz. The chassis mount style is suitable for integration into larger assemblies where space efficiency is prioritized. Verify that the 870 uA leakage current meets safety isolation requirements for the specific end-use application.

Part Context

This component belongs to the FN2500 series of EMC/EMI filters manufactured by TE Connectivity / Schaffner. The series offers various current ratings and configurations for single-phase applications. The FN2500-20-07-C13 specifically addresses needs for moderate current loads in industrial and commercial power systems requiring robust noise suppression.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
