Product Detailed Parameters
- Description：LINE FLTR 400VDC 277VAC 32A CHAS
- Series：FN2520
- Mfr：Schaffner EMC Inc.
- Package：Bulk
- Filter Type：Single Phase
- Configuration：Two Stage
- Voltage - Rated DC：400V
- Voltage - Rated AC：277V
- Current：32 A
- Frequency - Operating：DC ~ 60Hz
- Applications：General Purpose
- Approval Agency：CE, CQC, CSA, ENEC, UKCA, UR
- Operating Temperature：-40°C ~ 85°C
- Mounting Type：Chassis Mount
- Termination Style：Wire Leads
- Inductance：L1 - 900µH, L2 - 900µH
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The Schaffner FN2520-32-07-C1111 is a single-phase power line filter module designed for chassis mounting. It features a rated current of 32A and supports AC voltages up to 277VAC and DC voltages up to 400VDC. The unit utilizes Faston terminals for electrical connection and is engineered for operation within a temperature range of -25°C to +85°C. This component provides EMI/EMI filtering solutions suitable for industrial applications requiring robust performance in compact form factors.
Feature Summary
- Provides effective electromagnetic interference attenuation for single-phase power lines
- Designed for secure chassis mounting with standardized terminal connections
- Engineered for reliable operation across wide industrial temperature ranges
Applications
- Industrial machinery power supply units
- Medical equipment power modules
- Telecommunications infrastructure power systems
Procurement Notes
Verify the specific voltage rating (277VAC/400VDC) and current capacity (32A) against your system requirements. Confirm that the Faston terminal type matches your wiring harness. Ensure the chassis mounting dimensions are compatible with your enclosure design before procurement.
Selection Notes
Select this model when a single-phase filter with a 32A rating is required. Consider the physical dimensions and terminal style for integration. Evaluate if the specified voltage ratings meet the input power specifications of the target application environment.
Part Context
This component belongs to the FN2520 series of power line filters from Schaffner EMC Inc. The series offers various current ratings and configurations for single-phase applications, providing standardized EMC solutions for diverse electronic equipment needs.
Replacement Considerations
Check for other variants within the FN2520 series with different current ratings or terminal types. Verify compatibility with alternative single-phase chassis-mount filters from Schaffner or other manufacturers offering similar electrical specifications.
