FN2660-15-07-C0909

Overview

The Schaffner FN2660-15-07-C0909 is a single-phase, low-profile EMC/EMI power line filter from the FN2660 series. It features a chassis mount design with IEC 320 C20 input and C19 output connectors. The unit is rated for 250 VAC and 15 A current. Key electrical parameters include a maximum leakage current of 350 mA and operation at frequencies up to 60 Hz. The physical dimensions are approximately 35 mm in height, ensuring compact integration into equipment requiring efficient space utilization while maintaining high-performance noise suppression.

Feature Summary

• Provides effective electromagnetic interference suppression for single-phase AC power lines
• Utilizes a low-profile chassis mount form factor for space-constrained installations
• Integrates standard IEC 320 C20 inlet and C19 outlet interfaces for direct cable connection

Applications

• Medical equipment power supplies
• Industrial control systems
• Information technology hardware

Procurement Notes

Verify that the specific part number matches the required current rating and connector configuration for your application. Confirm compliance requirements such as RoHS status and regional safety certifications (e.g., UL, CE) with the manufacturer or authorized distributor before purchase. Ensure the chassis mounting style aligns with your enclosure design constraints.

Selection Notes

Select this component when a single-phase filter with a 15 A rating and IEC C19/C20 interface is required. Consider the low-profile height if vertical space within the equipment chassis is limited. Verify that the leakage current specifications meet the safety standards applicable to the end product, particularly for medical or sensitive electronic applications.

Part Context

This component belongs to the Schaffner FN2660 series, which offers a range of single-phase, low-profile EMC/EMI filters. The series is designed to provide high performance in a compact footprint, suitable for various commercial and industrial applications where space efficiency and noise reduction are critical priorities.

Replacement Considerations

Cross-reference with other FN2660 variants for different current ratings or connector types. Ensure any substitute maintains the same IEC interface compatibility and meets equivalent electrical and mechanical specifications.
