FN3288-20-33-C21-R65

$145.86

Description：LINE FILTER 530V/305VAC 20A CHAS
Series：FN 3288
Mfr：Schaffner EMC Inc.
Package：Bulk

SKU:b51b95029f10 Category: Power Line Filter Modules Brand: Schaffner EMC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LINE FILTER 530V/305VAC 20A CHAS
Series：FN 3288
Mfr：Schaffner EMC Inc.
Package：Bulk
Filter Type：Three Phase (Delta)
Configuration：Two Stage
Voltage - Rated DC：-
Voltage - Rated AC：530V, 305V
Current：20 A
Frequency - Operating：DC ~ 60Hz
Applications：Inverters, Power Drive Systems
Approval Agency：CE, ENEC, UR
Operating Temperature：-40°C ~ 100°C
Mounting Type：Chassis Mount
Termination Style：Terminal Block
Inductance：-
Voltage - Rated AC (Phase to Ground/Neutral)：305 V
Voltage - Rated AC (Phase to Phase)：530 V

Download product information

FN3288-20-33-C21-R65

Overview

The Schaffner FN3288-20-33-C21-R65 is a three-phase EMC power line filter rated for 20 A and 530 VAC. Designed for chassis mounting, it utilizes terminal block connections for secure installation. The component operates within a temperature range of -40°C to 100°C. It features a compact book-style housing that provides superior attenuation performance starting from 9 kHz. This model is part of the FN3288 series, engineered for high-performance noise suppression in space-constrained applications.

Feature Summary

Delivers superior electromagnetic interference attenuation performance beginning at 9 kHz
Utilizes a compact book-style housing design for efficient space utilization
Equipped with solid safety connector blocks for reliable terminal connections

Applications

Industrial power supplies
Battery charging systems
Energy-efficient electronic equipment

Procurement Notes

Verify the complete manufacturer part number against official Schaffner documentation to ensure correct configuration. Confirm that the specific suffix codes align with required electrical ratings and termination styles. Cross-reference datasheet specifications for voltage and current limits before integration. Ensure compliance with relevant safety standards applicable to the target deployment environment.

Selection Notes

Select this model when high attenuation performance is required from low frequencies up to 9 kHz. The chassis mount style suits fixed industrial installations. Verify that the 20 A current rating and 530 VAC voltage rating match the system requirements. Consider the compact form factor if panel space is limited compared to larger filter housings.

Part Context

This component belongs to the FN3288 series of three-phase EMC filters manufactured by Schaffner EMC Inc. The series is characterized by its slim profile and high attenuation capabilities. These filters are designed to meet stringent electromagnetic compatibility requirements for sensitive electronic loads and noisy power sources.
