FN3288-230-40-C26-R65

$656.28

Description：LINE FILTER 230A CHASSIS MOUNT
Series：FN 3288
Mfr：Schaffner EMC Inc.
Package：Bulk

SKU:0f841d73c067 Category: Power Line Filter Modules Brand: Schaffner EMC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LINE FILTER 230A CHASSIS MOUNT
Series：FN 3288
Mfr：Schaffner EMC Inc.
Package：Bulk
Filter Type：Three Phase (Delta)
Configuration：Two Stage
Voltage - Rated DC：-
Voltage - Rated AC：-
Current：230 A
Frequency - Operating：DC ~ 60Hz
Applications：Inverters, Power Drive Systems
Approval Agency：CE, ENEC, UKCA, UR
Operating Temperature：-40°C ~ 100°C
Mounting Type：Chassis Mount
Termination Style：Terminal Block
Inductance：-
Voltage - Rated AC (Phase to Ground/Neutral)：305 V
Voltage - Rated AC (Phase to Phase)：530 V

Download product information

FN3288-230-40-C26-R65

Overview

The Schaffner FN3288-230-40-C26-R65 is a three-phase (delta) EMC/EMI line filter rated for 230 A and 530 V AC. It operates at DC to 60 Hz with a two-stage configuration. The unit features terminal block connections and chassis mounting. Operating temperature range is -40°C to 100°C.

Feature Summary

Slim book-style design enables space-saving installation near inverters, converters, or motor drives.
Two-stage filtering topology provides effective EMI attenuation performance.

Applications

Inverter systems
Power drive systems

Procurement Notes

Verify the specific suffix codes against the manufacturer datasheet to confirm terminal type and capacitance values. Ensure the delta configuration matches the system requirements. Confirm RoHS compliance status if required by project specifications.

Selection Notes

Select this component for high-current three-phase applications requiring compact form factors. The slim profile allows placement close to power electronics. Verify that the 230 A rating and 530 V AC voltage align with the electrical system parameters.

Part Context

This part belongs to the FN 3287/FN 3288 series of slim book-style EMC filters. These filters are designed for inverter and power drive systems, offering a compact solution for electromagnetic interference suppression in industrial environments.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided documentation. Consult the manufacturer for direct equivalents or updated series replacements.
