FN3288HVIT-10-44-C26-R60

$142.26

Description：LINE FILTER 760VAC 10A CHASS MNT
Series：FN 3288
Mfr：Schaffner EMC Inc.
Package：Bulk

SKU:c7fb39de301e Category: Power Line Filter Modules Brand: Schaffner EMC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LINE FILTER 760VAC 10A CHASS MNT
Series：FN 3288
Mfr：Schaffner EMC Inc.
Package：Bulk
Filter Type：Three Phase (Delta)
Configuration：Two Stage
Voltage - Rated DC：-
Voltage - Rated AC：760V
Current：10:00 AM
Frequency - Operating：DC ~ 60Hz
Applications：Inverters, Power Drive Systems
Approval Agency：CE, ENEC, UR
Operating Temperature：-40°C ~ 100°C
Mounting Type：Chassis Mount
Termination Style：Terminal Block
Inductance：-
Voltage - Rated AC (Phase to Ground/Neutral)：-
Voltage - Rated AC (Phase to Phase)：-

Download product information

FN3288HVIT-10-44-C26-R60

Overview

The Schaffner FN3288HVIT-10-44-C26-R60 is a three-phase EMC/RFI power line filter designed for industrial applications. It features a two-stage configuration with terminal block input and output terminations. The unit supports an operating voltage range of 305 to 760 VAC and handles a current rating of 10 A. Key electrical specifications include a leakage current of 3.6 mA and operation within a temperature range of -40°C to 100°C at 60 Hz.

Feature Summary

Two-stage filtering architecture for enhanced noise attenuation
Terminal block termination for secure wiring connections
Chassis mount design for stable installation
Wide operating voltage compatibility

Applications

Industrial machinery power conditioning
Three-phase motor drive systems
Medical equipment power supplies
Telecommunications infrastructure

Procurement Notes

Verify the specific part number against official Schaffner documentation to ensure correct voltage and current ratings. Confirm that the terminal block type matches your system requirements. Check for updated compliance certifications such as UL, CE, or ENEC before finalizing procurement decisions.

Selection Notes

Select this component when a two-stage EMC filter is required for three-phase systems operating between 305 and 760 VAC. Ensure the chassis mount style fits the enclosure design. Verify that the 10 A current rating and 3.6 mA leakage current meet the safety and performance standards of the target application.

Part Context

This model belongs to the FN3288 series of power line filters manufactured by Schaffner EMC Inc., now part of TE Connectivity. The series is engineered for robust electromagnetic interference suppression in demanding environments. The HVIT designation indicates high-voltage insulation technology suitable for diverse industrial power networks.
