FN351-64-34

Overview

The Schaffner FN351-64-34 is a single-phase power line filter module designed for chassis mounting. It operates within a frequency range of DC to 400Hz and supports a rated current of 64A at voltages up to 520V AC. The unit features a two-stage configuration with a total inductance of 7.8mH, utilizing quick-connect terminals for installation. Certified by CSA, ENEC, and UR, it functions reliably between -25°C and +85°C.

Feature Summary

• Provides electromagnetic interference suppression for single-phase AC/DC applications
• Engineered for robust chassis mounting in industrial environments
• Complies with international safety certification standards

Applications

• Power drive systems
• Inverter installations
• General industrial machinery

Procurement Notes

Verify the specific suffix codes against official datasheets to ensure correct terminal style and voltage ratings. Confirm that the required certifications match local regulatory requirements before finalizing procurement orders.

Selection Notes

Select this component when high current capacity is required for single-phase lines. Ensure the mounting space accommodates the chassis form factor and that the operating temperature range aligns with the system environment.

Part Context

This model belongs to the FN351 series of Schaffner EMC filters. These units are specialized for handling high currents in power electronics, distinguishing them from lower-current appliance or signal line filters.

Replacement Considerations

Cross-reference tools indicate parametrically similar parts exist. Verify electrical specifications and physical dimensions before substituting.
