Product Detailed Parameters
- Description：LINE FILTER 80A CHASSIS MOUNT
- Series：FN 351
- Mfr：Schaffner EMC Inc.
- Package：Tray
- Filter Type：Three Phase (Delta)
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：-
- Current：80 A
- Frequency - Operating：DC ~ 60Hz
- Applications：Inverters, Power Drive Systems
- Approval Agency：CSA, ENEC, UR
- Operating Temperature：-25°C ~ 85°C
- Mounting Type：Chassis Mount
- Termination Style：Terminal Block
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：250 V
- Voltage - Rated AC (Phase to Phase)：440 V
Download product information
Overview
The Schaffner FN351-80-34 is a single-phase power line filter designed for electromagnetic compatibility in industrial environments. It features an 80A current rating and supports voltages up to 440VAC, with a maximum voltage of 520VAC. The unit utilizes terminal block connections and is engineered for chassis mounting. Operating within a frequency range of 0Hz to 60Hz, this component provides general-purpose EMC filtering suitable for demanding electrical equipment applications.
Feature Summary
- Provides general-purpose electromagnetic interference filtering for single-phase power lines
- Engineered for robust chassis mounting using industrial-grade terminal blocks
- Supports high current loads up to 80A at standard industrial voltages
Applications
- Electric equipment
- Uninterruptible Power Supplies (UPS)
- Machine tools
Procurement Notes
Verify the specific part number FN351-80-34 against official Schaffner documentation to ensure correct current and voltage ratings. Confirm that the chassis mount configuration and terminal block interface match your system requirements. Cross-reference manufacturer datasheets for precise technical specifications before procurement.
Selection Notes
Select this model for single-phase applications requiring 80A capacity and chassis installation. Ensure the operating voltage does not exceed 520VAC and the frequency aligns with 0Hz to 60Hz parameters. Validate that the terminal block connection method is compatible with existing wiring infrastructure.
Part Context
This component belongs to the FN351 series of power line filters from Schaffner EMC Inc. The series offers compact solutions for electromagnetic compatibility, featuring industrial-grade safety terminals. The FN351-80-34 variant specifically addresses higher current demands within single-phase systems.
Replacement Considerations
Consult official Schaffner documentation for verified substitute part numbers. Do not assume cross-compatibility with other series without explicit manufacturer confirmation regarding electrical ratings and physical dimensions.
