FN356-100-34

$754.64

Description：LINE FILTER 100A CHASSIS MOUNT
Series：FN 356
Mfr：Schaffner EMC Inc.
Package：Tray

SKU:ae39c1c2f9eb Category: Power Line Filter Modules Brand: Schaffner EMC Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

Product Detailed Parameters

Description：LINE FILTER 100A CHASSIS MOUNT
Series：FN 356
Mfr：Schaffner EMC Inc.
Package：Tray
Filter Type：Three Phase (Wye)
Configuration：Single Stage
Voltage - Rated DC：-
Voltage - Rated AC：-
Current：100 A
Frequency - Operating：DC ~ 60Hz
Applications：General Purpose
Approval Agency：CSA, ENEC, UR
Operating Temperature：-25°C ~ 100°C
Mounting Type：Chassis Mount
Termination Style：Terminal Block
Inductance：-
Voltage - Rated AC (Phase to Ground/Neutral)：250 V
Voltage - Rated AC (Phase to Phase)：440 V

Download product information

FN356-100-34

Overview

The Schaffner FN356-100-34 is a three-phase power line filter designed for chassis mounting. It supports a rated current of 100A and features a maximum leakage current of 1.33mA. The unit incorporates 24W of integrated heating capability to maintain performance in low-load environments. This component utilizes a three-phase plus neutral line configuration, providing essential electromagnetic interference suppression for industrial power distribution systems requiring high-current handling.

Feature Summary

Integrates 24W heating functionality for stable operation under varying load conditions
Engineered for high-current applications with a 100A rated capacity
Maintains minimal leakage current at 1.33mA for enhanced safety compliance

Applications

Three-phase industrial power distribution systems
General-purpose EMI filtering in heavy machinery
High-current power supply input stages

Procurement Notes

Verify component status as the FN356-100-34 is listed as discontinued by the manufacturer. Confirm availability through authorized distributors or secondary markets. Ensure replacement strategies account for end-of-life status. Validate technical specifications against original design requirements before procurement to avoid integration issues with obsolete inventory.

Selection Notes

Select this model specifically for three-phase systems requiring 100A continuous current handling. The integrated 24W heater is critical for environments where loads frequently drop below operational thresholds. Verify chassis mounting compatibility and terminal block connections. Consider the discontinued status when planning long-term production cycles and supply chain resilience.

Part Context

This component belongs to the Schaffner FN356 series of power line filters. The series is characterized by robust construction for industrial EMC applications. The FN356-100-34 variant specifically addresses high-current needs within the lineup, distinguishing itself through its 100A rating and built-in thermal management capabilities compared to lower-current counterparts.
