FN510-66-34

Overview

The Schaffner FN510-66-34 is a single-phase power line filter designed for chassis mounting. It features a rated current of 66 A and supports AC voltages up to 277 VAC. The unit utilizes terminal block connections for secure electrical interfacing. Designed for robust industrial environments, it operates within a temperature range of -40°C to +100°C. This component provides effective electromagnetic interference suppression for high-current applications.

Feature Summary

• Chassis mount design for secure installation in industrial enclosures
• Terminal block connection method ensuring reliable high-current interfacing
• Wide operating temperature range suitable for demanding environmental conditions

Applications

• Industrial machinery power conditioning
• Inverter output filtering
• High-current equipment EMI suppression

Procurement Notes

Verify the specific voltage rating and current capacity requirements against the application load before procurement. Confirm that the chassis mounting dimensions and terminal block configuration match the existing enclosure design. Ensure compliance with local safety standards and regulatory certifications required for the intended deployment region.

Selection Notes

Select this model when high continuous current handling is required alongside effective noise attenuation. Consider the thermal management capabilities given the wide operating temperature range. Evaluate the physical footprint constraints to ensure the chassis mount form factor fits the available space within the equipment housing.

Part Context

This component belongs to the FN510 series of power line filters manufactured by Schaffner EMC Inc. The series is characterized by high current ratings and durable construction for industrial use. The part number indicates specific electrical parameters including the 66 A current rating and 34 mm width dimension.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
