Product Detailed Parameters
- Description：LINE FILTER 8A CHASSIS MOUNT
- Series：FN 510
- Mfr：Schaffner EMC Inc.
- Package：Tray
- Filter Type：Three Phase (Delta)
- Configuration：-
- Voltage - Rated DC：-
- Voltage - Rated AC：-
- Current：8:00 AM
- Frequency - Operating：-
- Applications：General Purpose
- Approval Agency：-
- Operating Temperature：-25°C ~ 70°C
- Mounting Type：Chassis Mount
- Termination Style：Terminal Block
- Inductance：-
- Voltage - Rated AC (Phase to Ground/Neutral)：288 V
- Voltage - Rated AC (Phase to Phase)：500 V
Download product information
Overview
The FN510-8-29 is a single-phase power line filter manufactured by Schaffner EMC Inc. It features an 8 A current rating and supports voltage ratings of 110 VAC and 250 VAC. Designed for chassis mounting, this component utilizes terminal block connections for secure installation. The unit functions as an EMI/RFI filter module intended to suppress electromagnetic interference in AC power circuits.
Feature Summary
- Provides effective suppression of electromagnetic and radio frequency interference within AC power lines
- Engineered with a robust chassis mount design for stable mechanical integration into equipment enclosures
Applications
- Power supply units requiring input noise filtering
- Battery charger systems needing EMI protection
- Portable electronic devices utilizing AC mains input
Procurement Notes
Verify the exact electrical specifications against the official datasheet before procurement. Confirm that the 8 A rating and dual voltage support align with your system requirements. Ensure the chassis mount style matches your enclosure design. Check for any specific compliance certifications required for your target market.
Selection Notes
Select this model when an 8 A capacity is sufficient for the load. Consider the chassis mount form factor if panel or rack integration is necessary. Verify compatibility with both 110 VAC and 250 VAC operating environments. Ensure the terminal block interface suits the available wiring infrastructure.
Part Context
This component belongs to the FN510 series of power line filters from Schaffner EMC Inc. The series offers various current ratings and configurations for different industrial and commercial applications. Similar models include the FN510-4-29 and FN510-16-29, which provide alternative current capacities within the same product family.
Replacement Considerations
Direct substitutes within the FN510 series include the FN510-4-29 for lower current needs and the FN510-16-29 for higher current demands. Verify that any replacement maintains the same chassis mount style and terminal block connection type to ensure physical compatibility.
