FN530-8-99

Overview

The Schaffner FN530-8-99 is a three-phase EMC/EMI power line filter module designed for chassis mounting. It features an 8 A current rating and operates at 480 VAC. The unit utilizes a terminal block connection style with wire leads, providing robust noise suppression in industrial environments.

Feature Summary

• Three-stage filtering architecture for enhanced EMI/EMC attenuation
• Chassis mount design for secure installation
• Terminal block interface with integrated wire leads

Applications

• Industrial motor drives
• Power conversion systems
• Three-phase equipment requiring EMI suppression

Procurement Notes

Verify the specific datasheet version to confirm exact dimensional tolerances and terminal specifications. Ensure compatibility with existing chassis mounting holes and verify that the wire lead lengths meet the system integration requirements before finalizing procurement.

Selection Notes

Select this model when a three-phase solution with an 8 A continuous current rating is required. The terminal block configuration with wire leads simplifies wiring compared to busbar options. Confirm that the 480 VAC voltage rating aligns with the target power supply network.

Part Context

This component belongs to the Schaffner FN530 series of power line filters. The series offers various current ratings and connection styles to accommodate different industrial power conditioning needs. The FN530-8-99 specifically addresses applications requiring moderate current handling with convenient wiring access.

Replacement Considerations

Cross-reference with other FN530 variants such as FN530-12-99 or FN530-4-99 if current requirements differ. Verify that alternative models maintain the same chassis mount footprint and terminal block interface to ensure mechanical compatibility.
