FN610B-10-06

Overview

The Schaffner FN610B-10-06 is a single-phase EMI power line filter designed for AC mains applications. It features a compact, plug-in form factor with integrated fuse protection. The unit provides electromagnetic interference suppression across standard frequency ranges to ensure compliance with conducted emission standards. Rated for 10 Amperes at 250 Volts AC, it utilizes a robust construction suitable for industrial and commercial equipment integration.

Feature Summary

• Integrated fuse protection for enhanced safety
• Compact plug-in design for easy installation
• Single-phase EMI suppression capability

Applications

• Industrial control systems
• Commercial office equipment
• Medical devices requiring EMI filtering

Procurement Notes

Verify the specific ordering code against the manufacturer's current datasheet to confirm voltage ratings and fuse specifications. Ensure the input current requirements of the application do not exceed the 10A rating. Check for any regional certification marks required for the target market before finalizing procurement.

Selection Notes

Select this component when a single-phase solution with built-in overcurrent protection is required. Consider the physical dimensions for panel cutout compatibility. Evaluate the ambient temperature conditions to ensure the thermal rating remains within safe operational limits for the intended enclosure environment.

Part Context

This model belongs to the FN610 series of power line filters from Schaffner. The series is characterized by its small footprint and high performance in noise attenuation. It serves as a critical component for meeting regulatory emissions standards in various electronic assemblies.

Replacement Considerations

Consult official cross-reference lists for direct equivalents. Verify pin compatibility and mounting style before substitution. Ensure the replacement part meets or exceeds the original electrical ratings and certification requirements.
