Product Detailed Parameters
- Description：LINE FILTER 250VAC 10A CHASS MNT
- Series：FN 612
- Mfr：Schaffner EMC Inc.
- Package：Tray
- Filter Type：Single Phase
- Configuration：Single Stage
- Voltage - Rated DC：-
- Voltage - Rated AC：250V
- Current：10:00 AM
- Frequency - Operating：DC ~ 400Hz
- Applications：General Purpose
- Approval Agency：CSA, ENEC, UR
- Operating Temperature：-25°C ~ 100°C
- Mounting Type：Chassis Mount
- Termination Style：Quick Connect
- Inductance：450µH
- Voltage - Rated AC (Phase to Ground/Neutral)：-
- Voltage - Rated AC (Phase to Phase)：-
Download product information
Overview
The Schaffner FN612-10-06 is a single-phase power line filter module designed for chassis mounting. It features a rated voltage of 250 VAC and a continuous current rating of 10 A. The component operates within a frequency range of DC to 400 Hz, making it suitable for aerospace and industrial applications requiring 400 Hz performance. It utilizes Faston terminals for electrical connection and includes internal shielding to minimize leakage current. The unit weighs approximately 380 grams and is constructed for robust environmental durability.
Feature Summary
- Single-stage EMI/EMC filtering architecture
- Integrated internal shielding for enhanced noise suppression
- Chassis mount design with Faston terminal connections
Applications
- Aerospace power systems operating at 400 Hz
- Industrial machinery requiring single-phase line conditioning
- Medical equipment power input stages
Procurement Notes
Verify the specific suffix code against the manufacturer's latest documentation to confirm terminal type and certification status. Confirm availability as this series may be subject to discontinuation or limited stock. Ensure the receiving facility has appropriate handling procedures for chassis-mount components with Faston connectors. Cross-reference the part number with official TE Connectivity/Schaffner databases to validate current production status before finalizing procurement orders.
Selection Notes
Select this model when a single-phase filter with a 10 A rating is required for 250 VAC systems. It is appropriate for applications needing 400 Hz compatibility and chassis mounting. Verify that the available Faston terminal spacing matches the PCB or wire harness design. Consider the physical dimensions and weight constraints of the installation enclosure. Ensure the leakage current specifications meet the safety requirements of the end equipment.
Part Context
The FN612 series represents a line of single-phase power line filters from Schaffner. These components are engineered for general-purpose EMI suppression in AC power lines. The series offers various current ratings and mounting options to suit different industrial and commercial needs. The FN612-10-06 specifically addresses the 10 A requirement within this family.
FAQ
What is the maximum operating frequency for the FN612-10-06?
The component is rated for operation from DC up to 400 Hz.
How is the FN612-10-06 electrically connected?
It uses Faston terminals for electrical connection to the circuit.
