FN612-20-10

Overview

The FN612-20-10 is a three-phase power line filter from the Schaffner FN 612 series, designed for chassis mounting. It features a rated current of 20 A and a voltage rating of 250 VAC. The unit incorporates an inductance of 0.48 mH and operates within a frequency range of 0 Hz to 400 Hz. Key electrical specifications include a leakage current of 190 uA. The component utilizes Faston termination types for connection. It carries UL, CSA, and ENEC-14 compliance certifications. The device weighs approximately 630 g.

Feature Summary

• Provides electromagnetic interference suppression for three-phase power lines
• Engineered for robust chassis mounting applications
• Supports operation across standard industrial frequencies up to 400 Hz

Applications

• Industrial machinery power conditioning
• Three-phase equipment EMC mitigation
• Power supply input filtering

Procurement Notes

Verify component authenticity through authorized TE Connectivity or Schaffner channels. Confirm that the specific part number matches project requirements regarding current ratings and physical dimensions. Ensure compliance with local safety standards before integration into final assemblies.

Selection Notes

Select this model based on the required 20 A current capacity and 250 VAC voltage rating. Consider the 0.48 mH inductance value for appropriate noise attenuation levels. Verify that the Faston terminal type aligns with existing wiring infrastructure and chassis mounting constraints.

Part Context

This component belongs to the FN 612 series of power line filters manufactured by Schaffner EMC Inc., now part of TE Connectivity. The series is characterized by high-current handling capabilities and standardized mounting configurations suitable for demanding industrial environments.

Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation.
