FN670-6-06

Overview

The Schaffner FN670-6-06 is a two-stage AC power line filter designed for chassis mounting. It supports a rated current of 5A and operates at voltages up to 250VAC. The component utilizes faston terminals for electrical connection and is engineered for frequencies ranging from DC to 400Hz. This single-phase filter provides EMI suppression capabilities within an industrial-grade temperature range.

Feature Summary

• Two-stage filtering architecture for enhanced noise attenuation
• Chassis mount design for secure mechanical integration
• Faston terminal configuration for rapid circuit connection

Applications

• Industrial equipment power input stages
• Medical device power supplies
• General purpose electronic systems requiring EMI suppression

Procurement Notes

Verify the End of Life status before procurement, as this specific part number may be discontinued or subject to limited availability. Confirm that the faston terminal dimensions match existing PCB layouts. Ensure the 5A current rating and voltage specifications align with the target system requirements to prevent performance degradation.

Selection Notes

Select this component when a compact, two-stage solution is required for single-phase applications. The chassis mount style necessitates adequate panel space and thermal management considerations. Verify compatibility with the operating frequency range and ensure the enclosure material meets necessary safety standards for the intended deployment environment.

Part Context

This model belongs to the FN670 series of AC power line filters manufactured by Schaffner. The series is characterized by its robust construction and suitability for various industrial and commercial applications. The specific suffix indicates the current rating and terminal type configuration unique to this variant within the broader product family.

Replacement Considerations

Check for direct substitutes within the FN670 series or equivalent two-stage filters from other manufacturers. Ensure replacement parts maintain identical mounting dimensions and terminal styles to avoid redesigning the chassis or PCB layout.
