FN7510-100-M8

Overview

The Schaffner FN7510-100-M8 is a single-phase EMI feedthrough capacitor designed for panel mounting. It features an M20x1 threaded terminal interface and supports a rated voltage of 300 VAC with a current rating of 100 A. The component provides a capacitance value of 47 nF and exhibits a DC resistance of 0.23 mΩ. It operates within a temperature range of -40°C to +100°C.

Feature Summary

• Provides effective electromagnetic interference suppression through high-capacitance feedthrough design
• Engineered for robust mechanical stability using threaded terminal connections
• Capable of handling high continuous current loads in compact axial packages

Applications

• Computer server power distribution units
• Medical equipment power supplies
• Industrial control systems requiring EMI filtering

Procurement Notes

Verify the specific thread size designation, as some sources indicate M20x1 while others suggest M8 variants exist within the series. Confirm RoHS compliance status directly with the manufacturer or authorized distributor documentation before finalizing procurement specifications.

Selection Notes

Select this component when high current capacity and significant capacitance are required for single-phase applications. Ensure the mounting panel thickness accommodates the specified threaded terminal length and that the operating environment remains within the defined temperature limits.

Part Context

This part belongs to the FN751X series of EMI feedthrough capacitors manufactured by TE Connectivity / Schaffner. These components are specifically engineered for chassis or panel mounting applications where low impedance paths to ground are necessary for noise attenuation in sensitive electronic systems.

Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material.
