FR20C05VBDN

Headers, Receptacles, Female Sockets Overview

The FR20C05VBDN is a 10-position female receptacle connector manufactured by METZ CONNECT USA Inc. It features a 2.00 mm (0.079 inch) centerline pitch and is designed for through-hole mounting with solder termination. The contacts are gold-plated to ensure reliable electrical performance. This component belongs to the FR20C series, which provides vertical connection orientation at 0 degrees.

Headers, Receptacles, Female Sockets Feature Summary

• Female receptacle design suitable for board-to-board or cable connections
• Through-hole solderable construction for secure PCB attachment
• Gold contact plating for enhanced conductivity and corrosion resistance

Headers, Receptacles, Female Sockets Applications

• Industrial control systems requiring robust interconnects
• Automotive electronics assemblies
• General purpose electronic equipment

Headers, Receptacles, Female Sockets Procurement Notes

Verify the specific pin count and pitch against project requirements before ordering. Confirm that the through-hole mounting style aligns with the printed circuit board layout. Ensure compatibility with mating connectors in the FR20C series. Check environmental ratings if operation involves extreme temperatures or harsh conditions. Consult official datasheets for precise mechanical dimensions.

Headers, Receptacles, Female Sockets Selection Notes

Select this component when a 10-position vertical connector with a 2.00 mm pitch is required. Consider the gold plating for applications needing high reliability. Evaluate space constraints on the PCB due to the through-hole footprint. Compare against other series if different pitches or positions are needed. Ensure the housing material meets flame retardancy standards for the application.

Headers, Receptacles, Female Sockets Part Context

This part is part of the FR20C family from METZ CONNECT, specializing in circular and rectangular connectors. The series offers various pole counts and mounting options. METZ CONNECT focuses on industrial and automotive connectivity solutions. The FR20C series is known for its durability and standardized dimensions.

Headers, Receptacles, Female Sockets Replacement Considerations

Check for direct substitutes within the FR20C series with different pole counts. Verify cross-compatibility with other manufacturers' 2.00 mm pitch connectors. Ensure mechanical and electrical specifications match exactly before substitution.
