FS02-12

FS02-12 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists XP Power. Its product description is DC DC CONVERTER 200V 10W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for FS02-12

• Description：DC DC CONVERTER 200V 10W
• Series：XP EMCO - FS (10W)
• Mfr：XP Power
• Package：Box
• Type：High Voltage - Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：0.7V
• Voltage - Input (Max)：12V
• Voltage - Output 1：200V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：50mA
• Power (Watts)：10 W
• Voltage - Isolation：2.5 kV
• Applications：ITE (Commercial)
• Features：Proportional Output
• Operating Temperature：-25°C ~ 75°C
• Efficiency：85%
• Mounting Type：Through Hole
• Package / Case：4-DIP Module
• Size / Dimension：2.25" L x 1.12" W x 0.50" H (57.2mm x 28.5mm x 12.7mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-
