FSM15HL-TP

Single Diodes Overview

FSM15HL-TP is a standard single rectifier diode manufactured by Micro Commercial Components. It features a 600 V maximum DC reverse voltage and supports an average forward current of 1 A. The device utilizes SOD-123HL surface-mount packaging. Key electrical characteristics include a forward voltage of 1.3 V at 1 A, a reverse leakage current of 5 µA at 600 V, and a reverse recovery time of 250 ns. Junction capacitance is specified as 6.5 pF at 4 V and 1 MHz. The component operates within a junction temperature range of -55°C to +150°C.

Single Diodes Feature Summary

• High thermal stability with a maximum junction temperature rating of 150°C
• Fast switching capability with a 250 ns reverse recovery time
• Low leakage current performance under high reverse bias conditions

Single Diodes Applications

• General-purpose rectification in surface-mount circuits
• Power supply input stages requiring 600V isolation
• DC-DC converter freewheeling applications

Single Diodes Procurement Notes

Verify the specific suffix and package variant against the official MCC datasheet before ordering. Confirm RoHS compliance status and moisture sensitivity level requirements for your assembly process. Ensure the supplier provides traceable documentation matching the manufacturer's part number FSM15HL-TP to avoid counterfeit components.

Single Diodes Selection Notes

Select this component when a 1 A current rating and 600 V blocking voltage are required in a compact SOD-123HL footprint. The 250 ns recovery time makes it suitable for moderate-frequency switching applications. Compare forward voltage drop specifications against alternative fast recovery diodes if conduction loss is a critical design constraint.

Single Diodes Part Context

The FSM15HL-TP belongs to the FSM17HL series family from Micro Commercial Components. This series focuses on high-voltage rectification solutions using silicon planar technology. The SOD-123HL package offers improved thermal dissipation compared to standard SOD-123 variants, supporting reliable operation in dense PCB layouts.

Single Diodes Replacement Considerations

Publicly confirmed substitute part numbers are not available in the provided source material.
